A Heavy Series for Deep Rock Wells
Our deep rock water well drilling rigs are a heavy series from Hebei Zhongxin. Our factory started making mechanical parts in 1986. In 1996, we entered the drilling industry. Our factory covers more than 20 acres. We have over 30 years of experience. We have several models to choose from. Our main models are the ZXT-1000 and ZXT-1500. The ZXT-1000 with φ89 drill pipe reaches 800 to 1000 meters deep. Its rotary table opening is 600 mm. Torque is 12 kNm. Mast height is 15.3 meters. Load is 60 tons. Weight is 26 tons. The ZXT-1500 has a 660 mm rotary table opening. Its winch lift capacity is 90 kN. It comes with an F300 mud pump. Mast height can be up to 24 meters. Total weight is 42 tons. These deep rock water well drilling rigs are good for deep wells in hard rock.
Good for Geothermal and Uranium Wells
You can use them for geothermal wells. They also work for uranium extraction wells and grouting holes. We use them for building construction grouting holes and shallow gas holes. Our products have sold to the Middle East, Africa, Russia, and South America. Customers say our rigs are very durable and have few breakdowns. These rigs can use mud, foam, or air for drilling. They all have crawler tracks. They can drive on and off transport trucks by themselves. We produce to API standards. We have the ISO9001 quality certificate. Our factory has CNC friction welding machines, pipe end upsetting machines, straightening machines, and a semi-automatic hardening line.
Comparison Table of ZXT-1000 and ZXT-1500
|
Parameter |
ZXT-1000 |
ZXT-1500 |
|
Drilling Depth (φ89 pipe) |
800 - 1000 m |
Deeper |
|
Rotary Table Opening |
600 mm |
660 mm |
|
Max Torque |
12 kNm |
- |
|
Main Winch Lift Capacity |
50 kN |
90 kN |
|
Auxiliary Winch Capacity |
50 kN |
60 kN |
|
Mast Height (effective) |
15.3 m |
18.5 - 24 m |
|
Mast Rated Load |
60 tons |
70 tons |
|
Mud Pump |
F130 or F150 |
F300 |
|
Total Weight |
26 tons |
42 tons |
Lifetime Technical Help and Parts Supply
Our service is very honest. Before sale, we help you choose the right model. During production, we send photos and videos. After sale, we provide free lifetime technical help. We also supply parts for life. We can do video operation training. For some countries, we offer on-site service. These deep rock water well drilling rigs are reliable partners for your deep well work.
