A Pump Made for Water Well Rigs
Our mud pump for water well drilling is made by Hebei Zhongxin for water well rigs. Our factory was built in 1986. We have over 30 years of history. In 1996, we started making drilling equipment. Our factory covers more than 20 acres. We have our own R&D team. This pump works with our water well drill rigs. This pump is the F150 model. It is a horizontal three-cylinder single-acting piston pump. Its input power is 110 kW (150 HP). The rated stroke rate is 160 times per minute. The stroke length is 135 mm. The suction pipe diameter is 152 mm. The discharge pipe diameter is 64 mm. The size is 3180 mm x 1560 mm x 1560 mm. The total weight is 4500 kg. This mud pump for water well drilling is a perfect match for water well rigs.
Data Table for the F150 Pump
You can use it to drill water wells. It also works for farm irrigation wells and industrial water wells. We use it for geothermal wells and monitoring wells, too. Our products have gone to the Middle East, Africa, Russia, and South America. Customers say this pump works very well with their water well rigs. Below is the liner parameter table for the F150 model. Mechanical efficiency is 90%. Volumetric efficiency is 100%. Real data may have small differences.
|
Liner Diameter (mm) |
Theoretical Flow Rate (L/s) |
Rated Pressure (MPa) |
|
Φ110 |
10.25 |
10.0 |
|
Φ120 |
12.21 |
8.0 |
|
Φ130 |
14.32 |
7.0 |
|
Φ140 |
16.61 |
6.0 |
|
Φ150 |
19.08 |
5.0 |
Very Strict Quality and Excellent Service
We have very strict quality requirements. We produce to API standards. We do a 100% check on every product. We keep all production and test records. So you can trace every product. We have the ISO9001 certificate. Our factory has CNC friction welding machines, pipe end upsetting machines, straightening machines, and a semi-automatic hardening line. Our service is also excellent. Before sale, we discuss the matching plan with you in detail. During production, we send regular photos and videos. After sale, we provide free lifetime technical help. We also supply parts for life. We can train your workers by video. For some countries, we offer on-site service. This mud pump for water well drilling is a good partner for your water well work.
